A LIGHTWEIGHT MULTI SPOKE WHEEL WITH TAPERED PAIRED SPOKES EXTENDING TO THE OUTER LIP TO EMPHASISE THE RIM SIZE, A SIGNATURE DETAIL THAT RUNS THROUGHOUT THE IW RANGE.

The FFR1 was conceived to maximise the lightweight properties of the combined Motioncast™ and flow form processes.

Styled specifically to compliment modern high performance vehicles with a contemporary aesthetic such as BMW, VAG, Porsche and Mercedes.


Klarna
Why not spread the cost with Klarna?
Interest free finance available via our shop (UK only).

STANDARD FINISHES

IW Exclusive Finishes

HOME / WHEELS / FFR1

01

FFR1 Gallery

See the FFR1 in Action

FFR1 IW EXCLUSIVE FULL BRUSHED CARBON TITANIUM
FFR1 IW EXCLUSIVE FULL BRUSHED CARBON TITANIUM
FFR1 IW EXCLUSIVE MATT CARBON BRONZE
FFR1 IW EXCLUSIVE MATT CARBON BRONZE
FFR1 IW EXCLUSIVE FULL BRUSHED CARBON TITANIUM CAYMAN R
FFR1 IW EXCLUSIVE FULL BRUSHED CARBON TITANIUM

02

Specification

The FFR1 in Detail

A lightweight flow form wheel manufactured using IW FusionForged™ and Motioncast™ technologies, designed to enhance modern high performance vehicles.

Size Con Weight Max LD RRP
19 X 8.5 PC 10KG* 690KG £342.00
19 X 9 PC 10.9KG* 690KG £342.00
19 X 10 DC 11KG* 690KG £355.00
19 X 9.5 DC 10KG* 690KG £355.00
20 X 8.5 PC 10.7KG* 690KG £397.00
20 X 9 PC 11.6KG* 690KG £397.00
20 X 10 DC 11KG* 690KG £409.00
20 X 10.5 DC 11.9KG* 690KG £409.00
20 X 11 UC 11.9KG* 690KG £434.00
21 X 9 PC 12.1KG* 735KG £574.00
21 X 10.5 DC 12.9KG* 735KG £694.00

PLEASE NOTE
* Weights may differ depending on ET and stud pattern.
**Additional charge for IW Exclusive finishes, priced per set.

CONCAVE OPTIONS
PC = Performance Concave
DC = Deep Concave
STUD PATTERNS
BMW - 5 x 120
Ford RS - 5 x 108
Porsche - 5 x 130
Audi/VW/Mercedes - 5 x 112
Lexus/Nissan GTR - 5 x 114.3
WARRANTY
2 years warranty and lifetime structural integrity guarantee, click here for further details.

Please contact IW for fitment advice for your vehicle.
Please note prices shown include UK VAT at 20%

RegisterEd Design
The FFR1 is a registered IW
design (reg no: 002703397-0001)

03

Finishes

FFR1 Colour Options

IW Exclusive

Handcrafted finishes, special colours, discover IW Exclusive products

Discover

04

Technology

Combining Cutting Edge Technologies

MotionCast™ - The Pinnacle in casting technology

FFR wheels are initially cast using the IW Motioncast™ process, a superior form of casting that produces a denser alloy with less impurities and air pockets, allowing for a lighter and stronger wheel than traditional Low Pressure Cast wheels.

Low Pressure Cast Alloy

More impurities and air pockets within the alloy

IW Motioncast™

Less impurities and fewer air pockets within the alloy

IW Flow Form Technology

IW FusionForged™ utilises our state-of-the-art flow form technology. This process uses a special drum combined with heat and pressure applied by rollers that compress stretch and form the wheel barrel to a pre-defined thickness and desired profile.

This alters the structure of the aluminium forging a wheel barrel that is thinner, stronger and significantly lighter (approx 25%) than a traditional cast wheel, with enhanced strength and reduced weight properties comparable to fully forged wheels.

  • Fusionforged™ Step 1

    Each wheel is transferred from an oven to the flow forming drum. High pressure rollers move into position at the top of the wheel barrel.

  • Fusionforged™ Step 2

    The rollers move down the barrel applying pressure to compress, stretch and form the heated wheel barrel.

  • Fusionforged™ Step 3

    Flow forming alters the structure of the aluminium to produce a wheel barrel that is thinner, stronger and significantly lighter than traditional cast.

05

X2 System Design

FFR1 X2 Options

Mix It Up with X2

The FFR1 is an X2 compatible design and can be mixed in specific configurations with FFR2 to create a unique X2 look.

05

Concave Options

Two Concave Options Available

Performance Concave (PC)

Designed for maximum brake clearance suitable for larger brakes.

Concave Depth

19" - 45mm
20" - 47mm
21" - 38mm

Deep Concave (DC)

Front & rear wheel option in
specific widths.

Concave Depth

19" - 63mm
20" - 66mm
21" - 60mm
